GTH8 Built-in Ball Screw Actuator | 80mm High-Rigidity Linear Module
| Feature | Technical Data |
| Model | GTH8 (Built-in Integrated Rail) |
| Base Width | 80mm |
| Repeatability | +/-0.01 mm |
| Max. Horizontal Payload | Up to 50kg |
| Max. Vertical Payload | Up to 15kg |
| Max. Velocity | 400mm/s - 800mm/s |
| Screw Lead Options | 5mm, 10mm,20mm |
| Effective Stroke | 50mm -1200mm (Customizable) |
GTH8 Series: High-Rigidity Built-in Ball Screw Actuator
The GTH8 Series is the powerhouse of the compact GTH lineup. By integrating the guide rail system directly into the 80mm wide-body aluminum extrusion, the GTH8 achieves a perfect balance between a low-profile aesthetic and high-torque resistance. It is engineered for engineers who need a compact linear stage capable of handling heavier payloads with zero compromise on micron-level precision.
Key Advantages of GTH8 (Built-in Type)
The internal rail design, combined with its sleek profile, minimizes the entry of foreign particles, protecting the ball screw for a longer service life.
Application
The GTH8's high rigidity makes it ideal for more intensive automation tasks:
Automotive Parts Inspection: Stable motion for high-resolution 3D scanning.
Laser Cutting & Engraving: Vibration-free movement for intricate cutting paths.
Heavy-duty Pick & Place: Reliable handling for larger electronics and battery cells.
Multi-axis Gantries: Acts as a stable X or Y axis in desktop CNC or dispensing systems.
