CFS17 High-Precision Wide-Body Linear Module | 120kg Load & ±0.01mm Precision
| Feature | Technical Data |
| Drive Type | Precision Ball Screw (C7 Grade) |
| Repeatability | ±0.01mm |
| Max. Speed | 2000mm/s |
| Max. Payload | Horizontal: 120kg / Vertical: 50kg |
| Base Width | 170mm |
| Stroke Range | 100mm - 2500mm (Customizable) |
| Body Material | High-Strength Anodized Aluminum |
Product detail
The CFS17 Series is a premier industrial-grade linear actuator designed for high-load and high-stability applications. Featuring an ultra-wide 170mm base and an integrated (built-in) guide rail system, the CFS17 offers exceptional resistance to moment loads and structural deflection. It is the ideal choice for heavy-duty XYZ gantries, precision assembly, and high-speed industrial robotics.
Application Scenarios
Lithium Battery Manufacturing: Heavy-duty stacking and electrode coating.
Automotive Production: Robotic arm bases and heavy component assembly.
CNC & Laser Systems: High-speed motion for laser cutting and engraving heads.
Semiconductor & SMT: Vibration-free scanning for large-format inspection.
Ready for Engineering Integration
Universal Motor Mount: Compatible with 400/750W Servo motors and NEMA 34 Stepper motors.
CAD Models Available: Instant access to STEP/IGS files for seamless 3D design integration.
Low Maintenance: Self-lubricating components and a dust-proof design reduce the Total Cost of Ownership (TCO).
