HIWIN HGW25CC Linear Guide Block – HG Series Wide Flange Carriage for CNC Machine & Automation
| Model | Size | Type | Block Style |
|---|---|---|---|
| HGW15CC / HGW15HC | 15 mm | Wide block | Square flange |
| HGW20CC / HGW20HC | 20 mm | Wide block | Square flange |
| HGW25CC / HGW25HC | 25 mm | Wide block | Square flange |
| HGW30CC / HGW30HC | 30 mm | Wide block | Square flange |
| HGW35CC / HGW35HC | 35 mm | Wide block | Square flange |
| HGW45CC / HGW45HC | 45 mm | Wide block | Square flange |
Hiwin HGW Series Linear Guide Blocks
(HGW15 / HGW20 / HGW25 / HGW30 / HGW35 / HGW45)
Wide-Body Design | High Load Capacity | Smooth & Precise Linear Motion
The HIWIN HGW Series is a wide-body, heavy-load linear guide block designed for industrial-grade precision motion systems.
With optimized four-row circular-arc contact and equal load ratings in all directions, the HGW series is ideal for applications requiring high rigidity, superior accuracy, and long service life.
Perfect for CNC machines, automation systems, industrial robots, laser equipment, packaging machinery, and precision positioning devices.
Key Features & Advantages
Hiwin HGW Series Linear Guide Block (HGW15 / HGW20 / HGW25 / HGW30 / HGW35 / HGW45)
Available Models
| Model | Size | Type | Block Style |
|---|---|---|---|
| HGW15CC / HGW15HC | 15 mm | Wide block | Square flange |
| HGW20CC / HGW20HC | 20 mm | Wide block | Square flange |
| HGW25CC / HGW25HC | 25 mm | Wide block | Square flange |
| HGW30CC / HGW30HC | 30 mm | Wide block | Square flange |
| HGW35CC / HGW35HC | 35 mm | Wide block | Square flange |
| HGW45CC / HGW45HC | 45 mm | Wide block | Square flange |
CC = Standard preload
HC = Heavy preload
Application
CNC Milling Machines
Woodworking Machinery
Industrial Automation
Precision Positioning Systems
Robotics
Medical Equipment
PCB Machines
Laser Cutters & Engravers
Packaging Machinery
FAQ Section
Q1: Are these blocks original HIWIN?
A: Yes/No — depending on your business model. We provide original, replacement-compatible, and OEM options.
Q2: Can I order blocks with rails as a set?
A: Yes, we supply HGW blocks with matching HGR rails in any length.
Q3: Do you offer custom preload or lubrication?
A: Yes, options include C, H, P preload and custom grease filling.
Q4: Are stainless steel models available?
A: Yes, stainless versions are available upon request.
Q5: What is the lead time?
A: Stock models ship in 3–7 days; OEM products 10–25 days depending on quantity.
