Heavy Duty HGR20 Linear Rail Set | 2pcs Guide Rails + 4pcs HGH20CA Blocks + SFU1605 Ball Screw Kit for DIY CNC Router Engraving Machine
| Feature | Specification |
| Rail Model | HGR20 (20mm Width) |
| Block Model | HGH20CA (Square Type) |
| Ball Screw | SFU1605 (16mm Dia, 5mm Lead) |
| Material | GCr15 Bearing Steel / Carbon Steel |
| Accuracy Grade | C7 (Ball Screw), H (Linear Rail) |
| Application | CNC Routers, Lathes, Laser Engravers, Automation |
Professional HGR20 Linear Guide & Ball Screw Kit for CNC Automation
Upgrade your CNC machine or automation system with our industrial-grade HGR20 linear motion kit. This set is engineered for maximum rigidity, high precision, and long-term stability in demanding environments.
Superior Component Quality
The HGR20 rails provide a stable guiding surface, while the HGH20CA blocks utilize a four-row circular arc contact design to absorb even loads from all directions. Paired with the high-efficiency SFU1605 ball screw, you can achieve micron-level accuracy and zero backlash.
Technical Specifications
| Component | Material | Hardness | Accuracy Class |
|---|---|---|---|
| HGR20 Rail | GCr15 Chrome Steel | HRC 58-62 | H / P Class |
| SFU1605 Ball Screw | S55C / GCr15 | HRC 58-60 | C7 / C5 |
| Accessories | Aluminum / Cast Steel | - | Standard |
Application
Our kits are widely used in:
- CNC Machining Centers (Woodworking/Metalworking)
- 3D Printing & Large Scale Additive Manufacturing
- Laser Cutting & Engraving Machines
- Automatic Gantry Systems & Robotic Arms
- Precision Measuring Equipment
Application
Q: Is this HGR20 rail kit suitable for heavy-duty milling?
A: Yes, the HGR20 rails combined with HGH20CA high-load blocks provide the necessary rigidity for milling aluminum and wood.
Q: Does the SFU1605 ball screw come with end machined?
A: Our standard kits come with standard end machining for BK12/BF12 supports. Custom lengths are available upon request.
