HSR35R Type Linear Guide 35mm High Load Linear Motion System for CNC
| Parameter | Description |
|---|---|
| Model Type | HSR35R |
| Rail Width | 35 mm |
| Block Design | R Type (Extended / Heavy Load) |
| Contact Structure | Four-Row Rolling Contact |
| Base Material | Bearing Grade Steel |
| Accuracy Options | Standard / High |
| Preload Options | Light / Medium / Heavy |
| Lubrication Method | Grease |
| Mounting Style | Top Installation |
| Typical Use | CNC & Industrial Automation |
HSR35R Type Linear Guide
The HSR35R type linear guide is engineered for industrial motion systems that demand high structural stiffness, large load capacity, and stable positioning accuracy.
Featuring a 35mm rail profile and R-type extended block, this guide is well suited for large-format CNC machines and long-stroke automation equipment.
Its internal rolling system is based on a four-row contact arrangement, enabling balanced load distribution under multi-directional forces.
This design improves motion stability while reducing localized stress, ensuring consistent performance during long-term operation.
Through precision machining and controlled heat treatment, the guide achieves excellent dimensional stability and resistance to wear, making it a dependable solution for continuous industrial use.
Key Features of HSR35R Linear Guide
HSR35R type linear guides are widely used in heavy-duty linear motion systems, particularly where large loads and high stiffness are required.
The 35mm rail configuration provides a strong balance between load capacity, motion accuracy, and structural stability.
Application
The HSR35R linear guide is commonly applied in systems where high rigidity and load stability are critical, such as:
-
Large CNC machining equipment
-
Gantry-style motion platforms
-
Industrial automation assemblies
-
Linear axes for heavy machinery
-
Precision motion control frameworks
Its structural design supports long travel distances while maintaining motion accuracy.
Installation & Maintenance
Mounting surfaces should meet flatness and alignment requirements
-
Fasteners must be tightened evenly to specified torque values
-
Regular lubrication is recommended to ensure smooth rolling performance
-
Preload selection should match system load and accuracy targets
Proper setup significantly improves reliability and operational lifespan.
Customization & Supply Capability
To support different project requirements, we offer:
-
Rail length processing to specification
-
Multiple accuracy and preload configurations
-
OEM marking and customized packaging
-
Stable bulk supply for industrial customers
-
Technical consultation for system integration
These options allow flexible adaptation to various automation and CNC solutions.
-
